Define
Confirm product identity, drawing revision, dimensions, materials and operating requirements.
QUALITY & SUPPLY
Confidence comes
from the details.
We coordinate product requirements, supply and export preparation. Inspection scope and documentation are agreed for the specific product and order.
TESTING IN PRACTICE
Type testing as per EN 1074-2
Our water-supply gate valves are type-tested in accordance with EN 1074-2. Test requirements are matched to valve size, operating arrangement and pressure rating.
Bending test assembly
A gate valve installed between supported pipe sections with suspended loading.
Load application
Lever and suspended-load arrangement at the valve test bench.
Torque measurement
Manual torque-wrench operation on a gate valve in the test fixture.
Actual test-site photographs. Applied loads, instrument readings and acceptance results belong to the individual test record.
FROM SPECIFICATION TO SHIPMENT
Agree the requirement.
Check what matters.
Representative coating inspection photograph. Required methods, acceptance criteria and records depend on the order.
Coordinate
Review the selected configuration and align sample, production and inspection requirements with the supply partner.
Check
Agree dimensional, material, coating and functional checks appropriate to the product. Request the relevant records.
Prepare
Confirm packing, marking, document requirements and delivery arrangements before shipment.
DOCUMENTATION WITH CONTEXT
Standards belong
to a specific configuration.
A standard referenced in a product record is not a blanket certification for every size or option. Tell us the required standard, revision, application and destination so the relevant documents can be checked.
Current certificates and test documentation are supplied for review where applicable to the selected product. Historical certificates are not presented as current approvals.
Request project documentsPACKING & DOCUMENTS
Prepare for the destination.
- Agreed protection and packing method
- Product identification and marking
- Quantity and packing-list reconciliation
- Documents specified in the order
Requirements are confirmed for each shipment.
View packing photographs →
